GT-96180 Series
Manufacturer: GlobTek, Inc.
Beta
⌘K
POE INJECTOR 30V 18W DESKTOP
| Part | Output Connector | Input Connector | Features | Voltage - Output | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Standard Number | Approval Agency | Data Rate | Efficiency | Compliance | Type | Power (Watts) - Per Port | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output | Mounting Type | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C14 | OCP OVP SCP | 30 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 600 mA | Desktop | 1 |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C8 | OCP OVP SCP | 18 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CCC CE EAC ETL PSE RCM S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | Passive Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 1 A | Desktop | 1 | |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C8 | OCP OVP SCP | 48 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CCC CE EAC ETL PSE RCM S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | Passive Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 370 mA | Desktop | 1 | |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C14 | OCP OVP SCP | 18 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 1 A | Desktop | 1 |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C6 (Power) RJ45 (Data) | OCP OVP SCP | 56 V | 40.2 mm | 1.58 in | 104 mm | 54 mm | 4.09 in | 2.13 in | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 0.32 A | Wall Mount | 1 |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C14 | OCP OVP SCP | 19 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 950 mA | Desktop | 1 |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C8 | OCP OVP SCP | 30 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CCC CE EAC ETL PSE RCM S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | Passive Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 600 mA | Desktop | 1 | |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C14 | OCP OVP SCP | 48 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | 375 mA | Desktop | 1 |
 GlobTek, Inc. | RJ45 (Data Power) | IEC 320-C14 | OCP OVP SCP | 24 V | 35.7 mm | 1.41 " | 107 mm | 55 mm | 4.21 in | 2.17 " | 60335-1 60950-1 62368-1 | CB CE EAC ETL PSE S-Mark UkrSEPRO VCCI | 10 Mbps 100 Mbps 1000 Mbps | Level VI | IEEE802.3af | Midspan Injector | 18 W | 40 °C | -10 °C | 264 VAC | 90 VAC | Desktop | 1 |
