896-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 27POS 0.125
| Part | Termination Rows | Material - Insulation | Color | Number of Rows | Contact Finish | Mounting Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Positions/Bay/Row | Termination | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Contact Type | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | 3.25 mm | 0.128 " | Non Specified - Single Edge | Cantilever | Copper Alloy | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | 2.95 mm | 0.116 " | Non Specified - Single Edge | Cantilever | Copper Alloy | Floating Bobbin Flush Mount |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | 3.25 mm | 0.128 " | Non Specified - Single Edge | Cantilever | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | Non Specified - Single Edge | Cantilever | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Wire Wrap | Non Specified - Single Edge | Cantilever | Copper Alloy | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | Non Specified - Single Edge | Cantilever | Copper Alloy | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | 2.95 mm | 0.116 " | Non Specified - Single Edge | Cantilever | Copper Alloy | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | Non Specified - Single Edge | Cantilever | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | 3.25 mm | 0.128 " | Non Specified - Single Edge | Cantilever | Copper Alloy | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 1 | Gold | Right Angle Through Hole | 27 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Female | 125 °C | -40 C | Single | 27 | Solder | Non Specified - Single Edge | Cantilever | Copper Alloy | 4-40 Threaded Insert Top Mount Opening |
