12 mm Tact Switches
12 mm Tact Switches
| Part | Termination Style | Actuator Height off PCB, Vertical | Mechanical Life | Actuator Orientation | Mounting Type | Operating Force | Switch Function | Illumination | Actuator Material | Contact Rating @ Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Type | Circuit | Outline [y] | Outline [x] | Actuator Height off PCB, Vertical [z] | Actuator Length, Right Angle | Switch Travel [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Littelfuse/Commercial Vehicle Products | PC Pin | 8.5 mm | 200000 Cycles | Top Actuated | Through Hole | 0.25 kgf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Standard | SPST-NO | 12 mm | 12 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | 180 gf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Standard | SPST-NO | 12 mm | 12 mm | 4.3 mm | |||
Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Side Actuated | Through Hole Right Angle | 260 gf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Plunger for Cap | SPST-NO | 12 mm | 12 mm | 7.4 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | 260 gf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Plunger for Cap | SPST-NO | 12 mm | 12 mm | 7.3 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Plunger for Cap | SPST-NO | 12 mm | 12 mm | 7.3 mm | ||||
 Littelfuse/Commercial Vehicle Products | PC Pin | 1000000 Cycles | Top Actuated | Through Hole | 0.25 kgf | Off-Mom | Non-Illuminated | 0.05 A 12 VDC | -40 °C | 85 °C | Standard | SPST-NO | 12 mm | 12 mm | 4.3 mm | 0.3 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | 0.25 kgf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Plunger for Cap | SPST-NO | 12 mm | 12 mm | 7.3 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Standard | SPST-NO | 12 mm | 12 mm | 12 mm | ||||
 Littelfuse/Commercial Vehicle Products | PC Pin | 200000 Cycles | Top Actuated | Through Hole | 260 gf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Standard | SPST-NO | 12 mm | 12 mm | 12 mm | |||
 Littelfuse/Commercial Vehicle Products | PC Pin | 8.5 mm | 200000 Cycles | Top Actuated | Through Hole | 260 gf | Off-Mom | Non-Illuminated | Polybutylene Terephthalate (PBT) | 0.05 A 12 VDC | -40 °C | 60 °C | Standard | SPST-NO | 12 mm | 12 mm |
