spt Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
FUSE: FUSE; 16A; 250VAC; TIME-LAG; CERAMIC,CYLINDRICAL; 5X20MM; SPT
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case [y] | Package / Case | Package / Case [x] | Melting I²t | Mounting Type | Voltage Rating - AC | Voltage Rating - DC | Size / Dimension [diameter] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [diameter] | Current Rating (Amps) | Response Time | Breaking Capacity @ Rated Voltage | Fuse Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | -55 C | 125 °C | 20 mm | Axial | 5 mm | 1500 I²t | Through Hole | 250 V | 125 VDC | 0.213 in | 0.886 in | 22.5 mm | 5.4 mm | 16 A | Slow Blow | 1.5 kA 500 A | Cartridge Ceramic |
