7905-37 Series
Manufacturer: Oupiin
Beta
⌘K
CONN D-SUB PLUG 37POS VERT SLDR
| Part | Contact Material | Dielectric Material | Operating Temperature (Min) | Operating Temperature (Max) | Color | Number of Rows | Contact Type | Mounting Type | Shell Size | Connector Layout | Flange Feature | Contact Finish Thickness | Contact Finish Thickness (string set options) | Contact Finish Thickness | Finish | Shell Material | Number of Positions | Connector Style | Connector Type | Features | Contact Finish | Current Rating | Material Flammability Rating | Termination | Primary Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Oupiin | Brass | Polybutylene Terephthalate (PBT) | -55 °C | 105 °C | Black | 2 | Signal | Through Hole | 4 | C DC | Board Side (4-40) Female Screwlock (4-40) Mating Side | 0 | Flash | Flash | Tin Plated | Steel | 37 pos | D-Sub | Male Pins Plug | Board Lock Grounding Indents | Gold | 1 A | UL94 V-0 | Solder | |
 Oupiin | Brass | Polybutylene Terephthalate (PBT) | -55 °C | 105 °C | Black | 2 | Signal | Through Hole | 4 | C DC | Board Side (4-40) | 0 | Flash | Flash | Tin Plated | Steel | 37 pos | D-Sub | Female Sockets Receptacle | Gold | 1 A | UL94 V-0 | Solder | Metal | |
Oupiin | Brass | Polybutylene Terephthalate (PBT) | -55 °C | 105 °C | Black | 2 | Signal | Through Hole | 4 | C DC | Board Side (4-40) Female Screwlock (4-40) Mating Side | 0 | Flash | Flash | Tin Plated | Steel | 37 pos | D-Sub | Female Sockets Receptacle | Board Lock | Gold | 1 A | UL94 V-0 | Solder |
