TPSM265R1 Series
Manufacturer: Texas Instruments
Beta
⌘K
3-V TO 65-V INPUT, 100-MA, STEP-DOWN POWER MODULE IN 2.8 X 3.7 MM PACKAGE
| Part | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Current - Output (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package [y] | Supplier Device Package | Supplier Device Package [x] | Voltage - Output 1 | Type | Package / Case | Number of Outputs | Voltage - Input (Max) [Max] | Voltage - Input (Min) [Min] | Mounting Type | Efficiency | Features | Voltage - Output 1 [Min] | Voltage - Output 1 [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments | 1.6 mm | 3.8 mm | 0.06 " | 0.15 " | 0.12 in | 3 mm | 100 mA | 125 °C | -40 C | 3 | 10-uSIP | 3.8 | 3.3 V | Non-Isolated PoL Module | 10-LDFN Exposed Pad Module | 1 | 65 V | 3 V | Surface Mount | 77.2 % | |||
 Texas Instruments | 1.9 mm | 3.7 mm | 0.07 in | 0.15 " | 0.11 " | 2.8 mm | 100 mA | 125 °C | -40 C | 3 | 10-uSIP | 3.8 | 5 V | Non-Isolated PoL Module | 10-LDFN Exposed Pad Module | 1 | 65 V | 3 V | Surface Mount | 83 % | |||
 Texas Instruments | 1.6 mm | 3.8 mm | 0.06 " | 0.15 " | 0.12 in | 3 mm | 100 mA | 125 °C | -40 C | 3 | 10-uSIP | 3.8 | Non-Isolated PoL Module | 10-LDFN Exposed Pad Module | 1 | 65 V | 3 V | Surface Mount | Adjustable Output | 1.233 V | 15 V |
