CP30 Series
Manufacturer: Semiconductor Circuits, Inc.
Beta
⌘K
DC DC CONVERTER 3.3V 25W
| Part | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Voltage - Isolation | Mounting Type | Package / Case | Voltage - Input (Min) [Min] | Current - Output (Max) [Max] | Efficiency | Voltage - Input (Max) [Max] | Number of Outputs | Type | Applications | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Semiconductor Circuits, Inc. | 3.3 V | 0.94 in | 23.9 mm | 0.94 in | 23.9 mm | 8.9 mm | 0.35 in | 2250 VDC | Through Hole | 6-DIP Module | 9 V | 7.5 A | 89 % | 36 V | 1 | Isolated Module | ITE (Commercial) | 25 W | 123 °C | -40 °C |
