306-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 28POS 0.156
| Part | Material - Insulation | Termination Rows | Color | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Termination | Card Type | Contact Finish | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Contact Type | Number of Positions | Pitch | Pitch | Gender | Flange Feature | Read Out | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Tin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Copper Alloy | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount | Solder Eyelet(s) | Non Specified - Dual Edge | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount M3 Threaded Insert Top Opening | Dual | Copper Alloy | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount M3 Threaded Insert Top Opening | Dual | Copper Alloy | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount Top Opening Unthreaded | Dual | Copper Alloy | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Copper Alloy | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount | Solder Eyelet(s) | Non Specified - Dual Edge | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Copper Alloy | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Tin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount Top Opening Unthreaded | Dual | Copper Alloy | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Tin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount Side Opening Unthreaded | Dual | Copper Alloy | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Tin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Copper Alloy | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | -40 C | 105 ░C | Panel Mount Through Hole | Solder | Non Specified - Dual Edge | Tin | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 14 | Cantilever | 28 | 3.96 mm | 0.156 in | Female | Flush Mount Top Opening Unthreaded | Dual | Copper Alloy | 0.156 " | 3.96 mm |
