74LVC4066 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
SPST
| Part | Qualification | Mounting Type | Grade | Demultiplexer Outputs | Multiplexer Inputs | Charge Injection | Switch Time Ton (Max) | Switch Time Toff (Max) | Current - Leakage (Max) | Operating Temperature (Max) | Operating Temperature (Min) | -3db Bandwidth | On-State Resistance (Max) | Crosstalk | Voltage - Supply, Single (V+) (Minimum) | Voltage - Supply, Single (V+) (Maximum) | Package Width | Package Name | Package Length | Number of Circuits | Switch Circuit Type | Switch Contact | Channel Capacitance (CS(off)) | Channel Capacitance (CD(off)) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | AEC-Q100 | Surface Mount | Automotive | 1 | 1 | 7.5 pC | 5 ns | 6.5 ns | 20 µA | 125 °C | -40 °C | 500 MHz | 15 Ohm | -58 dB | 1.65 V | 5.5 V | 3.9 mm | 14-SO 14-SOIC | 0.154 in | 4 | SPST | NO | 8 pF | 8 pF |
