837-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 23POS 0.156
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Number of Rows | Contact Type | Termination | Contact Material | Read Out | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Color | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 23 | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Wire Wrap | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | 4-40 Threaded Insert Top Mount Opening | 23 | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | 4-40 Flush Mount Threaded Insert Top Opening | 23 | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 23 | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder Eyelet(s) | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 23 | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Wire Wrap | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | M3 Threaded Insert Top Mount Opening | 23 | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Flush Mount M3 Threaded Insert Top Opening | 23 | 125 °C | -40 C | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | 0.156 " | 3.96 mm | 23 | 125 °C | -40 C | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Wire Wrap | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 23 | 125 °C | -40 C |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | 1 | Cantilever | Solder | Copper Alloy | Single | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.25 Ám | 10 Áin | Gold | Green | 23 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 23 | 125 °C | -40 C |
