9987 Series

Catalog

HOOK-UP STRND 30AWG RED

Part	Ratings	Jacket (Insulation) Material	Wire Gauge	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length	Cable Type	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Voltage
Belden Inc. 9987 0021000	UL Style 1061	Poly-Vinyl Chloride (PVC)	30 AWG	0.25 mm	0.01 in	Red	0.032 in	0.81 mm	304.8 m	1000 ft	Hook-Up	Copper Tinned	38	7	300 VDC
Belden Inc. 9987 0071000	UL Style 1061	Poly-Vinyl Chloride (PVC)	30 AWG	0.25 mm	0.01 in	Violet	0.032 in	0.81 mm	304.8 m	1000 ft	Hook-Up	Copper Tinned	38	7	300 VDC
Belden Inc. 9987 0091000	UL Style 1061	Poly-Vinyl Chloride (PVC)	30 AWG	0.25 mm	0.01 in	White	0.032 in	0.81 mm	304.8 m	1000 ft	Hook-Up	Copper Tinned	38	7	300 VDC
