SFV18R Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN FFC BOTTOM 18POS 0.5MM R/A
| Part | Actuator Color | Mating Cycles | Current Rating (Amps) | Housing Color | Pitch | Pitch | FFC, FCB Thickness [custom] | FFC, FCB Thickness [custom] | Locking Feature | Contact Material | Features | Cable End Type | Housing Material | Voltage Rating | Number of Positions | Connector/Contact Type | Actuator Material | Contact Finish | Material Flammability Rating | Mounting Type | Flat Flex Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Height Above Board [z] | Height Above Board [z] | FFC, FCB Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Tin | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | ||
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | Flip Lock Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Notched Tabbed | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Tin | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | 0.3 mm | |||
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Gold | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | Flash | |
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Straight Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Tin | UL94 V-0 | Right Angle Surface Mount | FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | |||
 Amphenol ICC (FCI) | Brown | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Nylon Polyamide (PA) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled | Tin | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | |||
Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Gold | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | ||
Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Tin | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | ||
 Amphenol ICC (FCI) | Brown | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | 0.3 mm | 0.33 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Tapered | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Gold | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | ||
 Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | Flip Lock Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Notched Tabbed | Glass Filled Halogen Free Liquid Crystal Polymer (LCP) | 50 V | 18 | Contacts Top | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Tin | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | 0.3 mm | |||
Amphenol ICC (FCI) | Black | 20 | 0.5 A | Black | 0.02 " | 0.5 mm | Slide Lock | Phosphor Bronze | Solder Retention Zero Insertion Force (ZIF) | Straight Tapered | Glass Filled Halogen Free Nylon Polyamide (PA) | 50 V | 18 | Contacts Bottom | Polyphenylene Sulfide (PPS) Glass Filled Halogen Free | Gold | UL94 V-0 | Right Angle Surface Mount | FFC FPC | -55 C | 105 ░C | Solder | 0.071 in | 1.8 mm | 0.33 mm |
