170530 Series
Manufacturer: Molex
Beta
⌘K
IMPACT 85 OHM PLUS 3 PAIR RIGHT-ANGLE DAUGHTERCARD, LEFT GUIDE, 8 COLUMNS, 72 CIRCUITS, PLATED THROUGH HOLE DIMENSION 0.39MM, LEAD FREE
| Part | Number of Positions | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions Loaded | Termination | Contact Layout, Typical | Features | Connector Style | Number of Columns | Contact Finish | Color | Number of Rows | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Voltage Rating | Contact Layout, Typical |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 72 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | 24 Differential Pairs | Board Guide | Impact Guide Left | 8 | Gold | Gray | 9 | Receptacle Female Sockets | |||||
 Molex | 72 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | 24 Differential Pairs | Impact | 8 | Gold | Gray | 9 | Receptacle Female Sockets | ||||||
 Molex | 144 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | 48 Differential Pairs | Board Guide | 16 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | ||
 Molex | 90 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Impact | 10 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | 30 Differential Pairs | ||
 Molex | 144 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | 48 Differential Pairs | Board Guide | Impact Guide Left | 16 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | |
 Molex | 90 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Board Guide | Impact Guide Left | 10 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | 30 Differential Pairs | |
 Molex | 90 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Board Guide | 10 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | 30 Differential Pairs | ||
 Molex | 108 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Impact | 12 | Gold | Gray | 9 | Receptacle Female Sockets | -55 C | 85 °C | UL94 V-0 | 30 VDC | 36 Differential Pairs | ||
 Molex | 108 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Board Guide | 12 | Gold | Gray | 9 | Receptacle Female Sockets | 36 Differential Pairs | ||||||
 Molex | 108 | Board Edge Right Angle Through Hole | 30 Áin | 0.76 Ám | All | Press-Fit | Board Guide | Impact Guide Left | 12 | Gold | Gray | 9 | Receptacle Female Sockets | 36 Differential Pairs |
