SC68376 Series

Catalog

32BIT MCU, 8K ROM/ TRAY ROHS COMPLIANT: YES

Part	Core Size (Bit Width)	Core Configuration	Mounting Type	Package Length	Package Name	Package Width	Number of I/O	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	Program Memory Type	Package / Case	Oscillator Type	Connectivity	A/D Resolution (bits)	A/D Channels	Peripherals	Speed	RAM Size Depth	RAM Size Width	Core Processor	Operating Temperature (Max)	Operating Temperature (Min)
NXP USA Inc. SC68376BGMAB20	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	125 °C	-40 °C
NXP USA Inc. SC68376BGCAB25	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	25 MHz	7.5 K	8 bit	CPU32	85 °C	-40 °C
NXP USA Inc. SC68376BGVAB25	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	25 MHz	7.5 K	8 bit	CPU32	105 °C	-40 °C
NXP USA Inc. SC68376BGMAB20R	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	125 °C	-40 °C
NXP USA Inc. SC68376BAMAB20	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	125 °C	-40 °C
NXP USA Inc. SC68376BACAB25	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	25 MHz	7.5 K	8 bit	CPU32	85 °C	-40 °C
NXP USA Inc. SC68376BGCAB20	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	85 °C	-40 °C
NXP USA Inc. SC68376BGVAB20	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	105 °C	-40 °C
NXP USA Inc. SC68376BAVAB25	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	25 MHz	7.5 K	8 bit	CPU32	105 °C	-40 °C
NXP USA Inc. SC68376BACAB20	32 Bit	Single-Core	Surface Mount	28 mm	160-QFP	28 mm	18	5.25 V	4.75 V	ROMless	160-BQFP	External	CANbus EBI EMI SCI SPI	10 bit	16 count	POR PWM WDT	20 MHz	7.5 K	8 bit	CPU32	85 °C	-40 °C
