OSTOQ04 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
TERM BLOCK HDR 4POS 90DEG 5MM
| Part | Insulation Height [z] | Insulation Height [z] | Mounting Type | Housing Material | Material Flammability Rating | Contact Tail Length | Contact Tail Length | Contact Material | Type | Features | Voltage - UL | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Number of Positions | Number of Levels | Positions Per Level | Header Orientation | Termination Style | Contact Mating Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | UL94 V-0 | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (4 Side) | Mating Flange | 300 V | -30 ░C | 105 ░C | 0.197 in | 5 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin |
On Shore Technology Inc. | Solder Through Hole | Header Male Pins Shrouded (4 Side) | 300 V | 0.2 in | 5.08 mm | 4 | 1 | 4 | 90° Right Angle | Solder | |||||||||||
 On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Header Male Pins Shrouded (4 Side) | 300 V | -40 C | 115 °C | 0.2 in | 5.08 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin | |||
 On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (4 Side) | 300 V | -30 ░C | 105 ░C | 0.197 in | 5 mm | 4 | 1 | 4 | Vertical | Solder | Tin | ||
On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (4 Side) | 300 V | -30 ░C | 105 ░C | 0.295 in | 7.5 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin | ||
 On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (4 Side) | 300 V | -40 C | 115 °C | 0.197 in | 5 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin | ||
On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (2 Side) | 300 V | -30 ░C | 105 ░C | 0.3 in | 7.62 mm | 4 | 1 | 4 | Vertical | Solder | Tin | ||
On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | UL94 V-0 | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (4 Side) | Mating Flange | 300 V | -30 ░C | 105 ░C | 0.197 in | 5 mm | 4 | 1 | 4 | Vertical | Solder | Tin |
 On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (2 Side) | 300 V | -30 ░C | 105 ░C | 0.197 in | 5 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin | ||
On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | Thermoplastic | 0.157 in | 4 mm | Brass | Header Male Pins Shrouded (2 Side) | 300 V | -30 ░C | 105 ░C | 0.3 in | 7.62 mm | 4 | 1 | 4 | 90° Right Angle | Solder | Tin |
