SRP5020TA Series
Manufacturer: Bourns Inc.
Beta
⌘K
INDUCTOR, SHLD, 1UH, 7A, AEC-Q200
| Part | Shielding | Frequency - Self Resonant | Mounting Type | Package / Case | DC Resistance (DCR) [Max] | Type | Operating Temperature [Min] | Operating Temperature [Max] | Current - Saturation (Isat) | Tolerance | Material - Core | Ratings | Inductance | Current Rating (Amps) | Inductance Frequency - Test | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Q @ Freq [custom] | Q @ Freq [custom] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Q @ Freq [custom] | DC Resistance (DCR) | Q @ Freq | Q @ Freq [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Shielded | 64 MHz | Surface Mount | Nonstandard | 20 mOhm | Drum Core Wirewound | -40 C | 105 ░C | 13.7 A | 20 % | Metal | AEC-Q200 | 1 µH | 7 A | 100 kHz | 0.079 in | 2 mm | 13 | 100 kHz | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | ||||
 Bourns Inc. | Shielded | 30 MHz | Surface Mount | Nonstandard | Drum Core Wirewound | -40 C | 105 ░C | 5 A | 20 % | Metal | AEC-Q200 | 4.7 ÁH | 2.8 A | 100 kHz | 0.079 in | 2 mm | 18 | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 100 kHz | 116 mOhm | ||||
 Bourns Inc. | Shielded | 100 MHz | Surface Mount | Nonstandard | 8.6 mOhm | Drum Core Wirewound | -40 C | 105 ░C | 18 A | 20 % | Metal | AEC-Q200 | 470 nH | 11.5 A | 100 kHz | 0.079 in | 2 mm | 11 | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 100 kHz | ||||
Bourns Inc. | Shielded | 35 MHz | Surface Mount | Nonstandard | 76 mOhm | Drum Core Wirewound | -40 C | 105 ░C | 20 % | Metal | AEC-Q200 | 3.3 µH | 3.3 A | 100 kHz | 0.079 in | 2 mm | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 17 100 kHz | ||||||
Bourns Inc. | Shielded | 18 MHz | Surface Mount | Nonstandard | Drum Core Wirewound | -40 C | 105 ░C | 3.4 A | 20 % | Metal | AEC-Q200 | 10 µH | 2.3 A | 100 kHz | 0.079 in | 2 mm | 100 kHz | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 199 mOhm | 22 | ||||
 Bourns Inc. | Shielded | 20 MHz | Surface Mount | Nonstandard | 171 mOhm | Drum Core Wirewound | -40 C | 105 ░C | 3.5 A | 20 % | Metal | AEC-Q200 | 8.2 µH | 2.3 A | 100 kHz | 0.079 in | 2 mm | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 21 100 kHz | |||||
Bourns Inc. | Shielded | 58 MHz | Surface Mount | Nonstandard | Drum Core Wirewound | -40 C | 105 ░C | 11 A | 20 % | Metal | AEC-Q200 | 1.2 µH | 6.2 Amps | 100 kHz | 0.079 in | 2 mm | 5.7 mm | 0.205 " | 0.224 " | 5.2 mm | 28 mOhm | 14 100 kHz |
