23_SMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
23_SMA-50-0-272/133_NH
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Center Contact Plating | Body Material | Dielectric Material | Body Finish | Frequency - Max [Max] | Impedance | Number of Ports | Mounting Feature | Contact Termination | Connector Type | Fastening Type | Shield Termination | Connector Style | Housing Color | Mounting Type | Center Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | -65 ░C | 165 °C | 500 | Gold | Brass | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Silver | Panel Mount | Beryllium Copper | |
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Gold | Panel Mount | Beryllium Copper | |
Huber+Suhner, Inc. | -65 ░C | 165 °C | 500 | Gold | Stainless Steel | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Silver | Panel Mount | Beryllium Copper | ||
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | 18 GHz | 50 Ohms | 1 | Flange | Solder Cup | Female Socket Jack | Threaded | Solder | SMA | Gold | Panel Mount | Beryllium Copper | |
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Gold | Panel Mount Through Hole | Beryllium Copper | Extended Insulation |
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Gold | Panel Mount | Beryllium Copper | Extended Insulation |
 Huber+Suhner, Inc. | 18 GHz | 50 Ohms | 1 | Flange | Solder Cup | Female Socket Jack | Threaded | Solder | SMA | Silver | Panel Mount | Beryllium Copper | ||||||||
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Beryllium Copper | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Gold | Panel Mount | Beryllium Copper | |
 Huber+Suhner, Inc. | -65 ░C | 125 °C | 500 | Gold | Stainless Steel | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 18 GHz | 50 Ohms | 1 | Flange | Solder Cup | Female Socket Jack | Threaded | Solder | SMA | Silver | Panel Mount | Beryllium Copper | ||
 Huber+Suhner, Inc. | -65 ░C | 165 °C | 500 | Gold | Stainless Steel | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | 18 GHz | 50 Ohms | 1 | Flange | Solder | Female Socket Jack | Threaded | Solder | SMA | Silver | Panel Mount | Beryllium Copper | Extended Insulation |
