G11ME7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT,STY1,SZ1,10
| Part | Material Flammability Rating | Voltage Rating | Contact Finish - Mating | Mounting Feature | Contact Material | Connector Type | Shielding | Shell Size - Insert | Primary Material | Shell Material | Applications | Ingress Protection | Number of Positions | Fastening Type | Color | Current Rating (Amps) | Insert Material | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Mounting Type | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
UL94 V-0 | 25 V | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 10 | Detent Lock Push-Pull | Gray Green | 4 A | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount | ||
UL94 V-0 | 33 V | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 9 | Detent Lock Push-Pull | Blue Gray | 4 A | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount Through Hole | Solder | |
UL94 V-0 | 33 V | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 6 | Detent Lock Push-Pull | Gray | 7.5 A | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount | ||
UL94 V-0 | 48 VDC | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 2 | Detent Lock Push-Pull | 12 Amps | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount | |||
UL94 V-0 | 48 VDC | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 2 | Detent Lock Push-Pull | Blue Gray | 12 Amps | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount | ||
UL94 V-0 | 48 VDC | Gold | Bulkhead - Rear Side Nut | Brass | Receptacle Female Sockets | Unshielded | 1 | Plastic | Polysulfone (PSU) | Industrial Medical Testing Equipment & Measurement | IP50 - Dust Protected | 2 | Detent Lock Push-Pull | Gray Yellow | 12 Amps | Polyetheretherketone (PEEK) | 120 °C | -50 °C | E | Panel Mount |
