8461 Series

Catalog

MULTIPAIR CABLE, AUDIO CONTROL, UNSHIELDED, 1 PAIR, 18 AWG, 500 FT, 152.4 M

Part	Length	Length	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Jacket Color	Conductor Material	Number of Conductors	Conductor Insulation	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Usage	Length	Voltage	Length [x]	Length [x]
Belden Inc. 8461 060U500	152.4 m	500 ft	80 °C	-20 ░C	5.94 mm	0.234 in	Speaker	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG
Belden Inc. 8461 0605000			80 °C	-20 ░C	5.94 mm	0.234 in	Multi-Conductor	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG	Audio Control Instrumentation	Enter Number of Feet in Order Quantity	300 VDC
Belden Inc. 8461 060500	152.4 m	500 ft	80 °C	-20 ░C	5.94 mm	0.234 in	Multi-Conductor	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG	Audio Control Instrumentation		300 VDC
Belden Inc. 8461 060100			80 °C	-20 ░C	5.94 mm	0.234 in	Speaker	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG				100 ft	30.5 m
Belden Inc. 8461 060U1000	304.8 m	1000 ft	80 °C	-20 ░C	5.94 mm	0.234 in	Multi-Conductor	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG	Audio Control Instrumentation		300 VDC
Belden Inc. 8461 0601000	304.8 m	1000 ft	80 °C	-20 ░C	5.94 mm	0.234 in	Multi-Conductor	Chrome	Copper Tinned	2	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)	0.686 mm	0.027 "	26 AWG	7	18 AWG	Audio Control Instrumentation		300 VDC
