M1BXK Series

Manufacturer: 3M (TC)

Catalog

IDC CABLE - MSR40K/MC40M/X

Part	Length [x]	Length [x]	Pitch - Cable	Pitch - Cable	Color	Features	Cable Termination	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Number of Positions	Connector Type	Shielding	Number of Rows	Pitch - Connector	Pitch - Connector
3M (TC) M1BXK-4036R	3 ft	914.4 mm	0.05 "	1.27 mm	Multiple Ribbon	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	40	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-6036J	3 ft	914.4 mm	0.05 "	1.27 mm		Strain Relief	IDC	Gold	0.76 Ám	30 Áin	60	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-3036R	3 ft	914.4 mm	0.05 "	1.27 mm	Multiple Ribbon	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	30	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-6036R	3 ft	914.4 mm	0.05 "	1.27 mm	Multiple Ribbon	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	60	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-1040K	3.34 ft	1.02 m	0.05 "	1.27 mm	Multiple Twisted Pair (Flat)	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	10	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-2040K	3.34 ft	1.02 m	0.05 "	1.27 mm	Multiple Twisted Pair (Flat)	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	20	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-1036J	3 ft	914.4 mm	0.05 "	1.27 mm		Strain Relief	IDC	Gold	0.76 Ám	30 Áin	10	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-3440K	3.34 ft	1.02 m	0.05 "	1.27 mm	Multiple Twisted Pair (Flat)	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	34	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-6040K	3.34 ft	1.02 m	0.05 "	1.27 mm	Multiple Twisted Pair (Flat)	Strain Relief	IDC	Gold	0.76 Ám	30 Áin	60	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
3M (TC) M1BXK-2436J	3 ft	914.4 mm	0.05 "	1.27 mm		Strain Relief	IDC	Gold	0.76 Ám	30 Áin	24	Socket to Cable	Unshielded	2	0.1 in	2.54 mm
