QK025K6TP Series

Altnstr 1000V 25A 80-80-80 mA TO220 Iso

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Altnstr 1000V 25A 80-80-80 mA TO220 Iso

Part	Current - On State (It (RMS)) (Max) [Max]	Voltage - Gate Trigger (Vgt) (Max) [Max]	Current - Non Rep. Surge 50, 60Hz (Itsm)	Package / Case	Current - Hold (Ih) (Max) [Max]	Supplier Device Package	Voltage - Off State	Configuration	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Triac Type	Current - Gate Trigger (Igt) (Max) [Max] [custom]	Current - Gate Trigger (Igt) (Max) [Max]
Littelfuse/Commercial Vehicle Products QK025K6TP	25 A	1.3 V	208 A 250 A	TO-218-3 Isolated Tab TO-218AC	100 mA	TO-218 Isolated Tab	1 kV	Single	-40 °C	125 ¯C	Through Hole	Alternistor - Snubberless	80 mA
Littelfuse/Commercial Vehicle Products QK025R6TP	25 A	1.3 V	208 A 250 A	TO-220-3	100 mA	TO-220AB	1 kV	Single	-40 °C	125 ¯C	Through Hole	Alternistor - Snubberless	80 mA
Littelfuse/Commercial Vehicle Products QK025L6	25 A	1.3 V	208 A 250 A	TO-220-3 Isolated Tab	100 mA	TO-220 Isolated Tab	1 kV	Single	-40 °C	125 ¯C	Through Hole	Alternistor - Snubberless	80 mA
Littelfuse/Commercial Vehicle Products QK025N5TP	25 A	1.3 V	167 A 200 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	100 mA	TO-263 (D2PAK)	1 kV	Single	-40 °C	125 ¯C	Surface Mount	Standard		50 mA
Littelfuse/Commercial Vehicle Products QK025R5	25 A	1.3 V	167 A 200 A	TO-220-3	100 mA		1 kV	Single	-40 °C	125 ¯C	Through Hole	Standard		50 mA
Littelfuse/Commercial Vehicle Products QK025NH6TP	25 A	1.3 V	208 A 250 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	100 mA	TO-263 (D2PAK)	1 kV	Single	-40 °C	125 ¯C	Surface Mount	Alternistor - Snubberless	80 mA
Littelfuse/Commercial Vehicle Products QK025N5RP	25 A	1.3 V	167 A 200 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	100 mA	TO-263 (D2PAK)	1 kV	Single	-40 °C	125 ¯C	Surface Mount	Standard		50 mA
Littelfuse/Commercial Vehicle Products QK025NH6RP	25 A	1.3 V	208 A 250 A	D2PAK (2 Leads + Tab) TO-263-3 TO-263AB	100 mA	TO-263 (D2PAK)	1 kV	Single	-40 °C	125 ¯C	Surface Mount	Alternistor - Snubberless	80 mA
Littelfuse/Commercial Vehicle Products QK025L6TP	25 A	1.3 V	208 A 250 A	TO-220-3 Isolated Tab	100 mA	TO-220AB-L	1 kV	Single	-40 °C	125 ¯C	Through Hole	Alternistor - Snubberless	80 mA

Catalog

Altnstr 1000V 25A 80-80-80 mA TO220 Iso

Key Features

• RoHS compliant

• Glass-passivated junctions

• Voltage capability up to 1 kV

• Surge capability up to 250 A

Description

25 Amp bi-directional solid state switch series is designed for AC switching and phase control applications such as motor speed and temperature modulation controls, lighting controls, and static switching relays. Standard type devices normally operate in Quadrants I & III triggered from AC line. Alternistor type devices only operate in quadrants I, II, & III and are used in circuits requiring high dv/dt capability.
