VI-JT1 Series

Catalog

DC DC CONVERTER 12V 25W

Part	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	Package / Case	Voltage - Input (Min) [Min]	Voltage - Output 1	Voltage - Isolation	Efficiency	Features	Voltage - Input (Max) [Max]	Type	Current - Output (Max) [Max]	Mounting Type	Applications	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]
Vicor Corporation VI-JT1-EZ-B1	27.4 mm	59.9 mm	2.28 in	1.08 "	57.9 mm	2.36 "	25 W	Half Brick	66 V	12 V	3000 V	88 %	OCP SCP	160 V	Isolated Module	2.08 A	Through Hole	ITE (Commercial)	1
Vicor Corporation VI-JT1-CZ-S	13.2 mm	57.9 mm	1.8 in	0.52 in	45.7 mm	2.28 "	25 W	Half Brick	66 V	12 V	3000 V	90 %	OCP SCP	160 V	Isolated Module	2.08 A	Through Hole	ITE (Commercial)	1	100 °C	-25 °C
Vicor Corporation VI-JT1-CZ	12.7 mm	57.9 mm	2.4 in	0.5 in	70 mm	2.28 "	25 W	Half Brick	66 V	12 V	3000 V	90 %	OCP SCP	160 V	Isolated Module	2.08 A	Through Hole	ITE (Commercial)	1	100 °C	-25 °C
Vicor Corporation VI-JT1-CW	12.7 mm	57.9 mm	2.4 in	0.5 in	70 mm	2.28 "	100 W	Half Brick	66 V	12 V	3000 V	90 %	OCP SCP	160 V	Isolated Module	8.33 A	Through Hole	ITE (Commercial)	1	100 °C	-25 °C
Vicor Corporation VI-JT1-EZ	12.7 mm	57.9 mm	2.4 in	0.5 in	70 mm	2.28 "	25 W	Half Brick	66 V	12 V	3000 V	88 %	OCP SCP	160 V	Isolated Module	2.08 A	Through Hole	ITE (Commercial)	1
Vicor Corporation VI-JT1-EW	12.7 mm	57.9 mm	2.4 in	0.5 in	70 mm	2.28 "	100 W	Half Brick	66 V	12 V	3000 V	88 %	OCP SCP	160 V	Isolated Module	8.33 A	Through Hole	ITE (Commercial)	1
Vicor Corporation VI-JT1-EY-F2	26.4 mm	57.9 mm	1.86 in	1.04 in	47.2 mm	2.28 "	50 W	Half Brick	66 V	12 V	3000 V	88 %	OCP SCP	160 V	Isolated Module	4.17 A	Through Hole	ITE (Commercial)	1
Vicor Corporation VI-JT1-CY	12.7 mm	57.9 mm	2.4 in	0.5 in	70 mm	2.28 "	50 W	Half Brick	66 V	12 V	3000 V	90 %	OCP SCP	160 V	Isolated Module	4.17 A	Through Hole	ITE (Commercial)	1	100 °C	-25 °C
Vicor Corporation VI-JT1-CZ-B1	27.4 mm	59.9 mm	2.28 in	1.08 "	57.9 mm	2.36 "	25 W	Half Brick	66 V	12 V	3000 V	90 %	OCP SCP	160 V	Isolated Module	2.08 A	Through Hole	ITE (Commercial)	1	100 °C	-25 °C
Vicor Corporation VI-JT1-EW-B1	27.4 mm	59.9 mm	2.28 in	1.08 "	57.9 mm	2.36 "	100 W	Half Brick	66 V	12 V	3000 V	88 %	OCP SCP	160 V	Isolated Module	8.33 A	Through Hole	ITE (Commercial)	1
