833-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 38POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Number of Positions | Read Out | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Card Type | Contact Material | Number of Positions/Bay/Row | Contact Finish | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Color | Gender | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Features | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Green | Female | Solder Eyelet(s) | 125 °C | -40 C | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | Card Extender | 0.116 " | 2.95 mm | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Green | Female | Wire Wrap | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | Green | Female | Solder Eyelet(s) | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 38 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | 1 | 1 | 38 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 38 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm | 1 | 1 | 38 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | Card Extender | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 38 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Non Specified - Single Edge | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Green | Female | Solder | 125 °C | -40 C | 3.96 mm | 0.156 in | 1 | 1 | 38 | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | 38 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Non Specified - Dual Edge | Copper Alloy | 19 | Gold | Cantilever | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | Green | Female | Wire Wrap | 125 °C | -40 C | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm |
