CFT2-1FC Series
Manufacturer: Nidec Components Corporation
Beta
⌘K
SWITCH TOGGLE SPDT 0.4VA 28V
| Part | Electrical Life | Features | Voltage Rating - AC | Voltage Rating - DC | Illumination | Operating Temperature [Max] | Operating Temperature [Min] | Actuator Length [x] | Actuator Type | Circuit | Switch Function | Termination Style | Current Rating (Amps) | Mounting Type | Bushing Thread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nidec Components Corporation | 10000 Cycles | Gray Actuator Washable | 28 V | 28 V | Non-Illuminated | 85 °C | -40 °C | 3.8 mm | Standard Round | SPDT | On-Mom | PC Pin | 0.4 VA | Through Hole Right Angle | Unthreaded |
 Nidec Components Corporation | 10000 Cycles | Gray Actuator Washable | 28 V | 28 V | Non-Illuminated | 85 °C | -40 °C | 3.8 mm | Standard Round | SPDT | On-Mom | PC Pin | 0.4 VA | Through Hole | Unthreaded |
