Transient Voltage Suppressor (AEC-Q101 Qualified)
Description
AI
SMF7V0TF is a transient voltage suppressor with small mold package, suitable for surge protection. It is a highly reliable product for automotive.
Beta
⌘K
Transient Voltage Suppressor (AEC-Q101 Qualified)
Transient Voltage Suppressor (AEC-Q101 Qualified)
| Part | Operating Temperature | Mounting Type | Voltage - Clamping (Max) @ Ipp [Max] | Voltage - Breakdown (Min) [Min] | Grade | Voltage - Reverse Standoff (Typ) | Supplier Device Package | Power Line Protection | Unidirectional Channels [custom] | Package / Case | Qualification | Type | Power - Peak Pulse | Current - Peak Pulse (10/1000µs) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 150 °C | Surface Mount | 12 V | 7.78 V | Automotive | 7 V | PMDU | 1 | SOD-123F | AEC-Q101 | Zener | 200 W | 16.7 A | ||
 Rohm Semiconductor | 150 °C | Surface Mount | 12 V | 7.78 V | 7 V | PMDU | 1 | SOD-123F | Zener | 200 W | 16.7 A | General Purpose |
