EET-HD Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP ALUM 180UF 20% 450V SNAP TH

Part	Polarization	Capacitance	Tolerance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Mounting Type	Size / Dimension [diameter]	Size / Dimension [diameter]	Lifetime @ Temp.	Applications	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Ripple Current @ High Frequency	Ripple Current @ Low Frequency	Voltage - Rated	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales EET-HD2W181HJ	Polar	180 çF	20 %	37 mm	1.457 in	Through Hole	22 mm	0.866 in	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.218 A	870 mA	450 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2W471LJ	Polar	470 µF	20 %	37 mm	1.457 in	Through Hole	35 mm	1.378 in	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	2.436 A	1.74 A	450 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2S121HJ	Polar	120 µF	20 %	27 mm	1.063 in	Through Hole	22 mm	0.866 in	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.036 A	740 mA	420 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2W221HJ	Polar	220 µF	20 %	47 mm	1.85 in	Through Hole	22 mm	0.866 in	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.4 A	1 A	450 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2S271KJ	Polar	270 µF	20 %			Through Hole	30 mm	1.181 inches	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.68 A	1.2 A	420 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2G561KJ	Polar	560 µF	20 %			Through Hole	30 mm	1.181 inches	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	2.66 A	1.9 A	400 V	0.394 in	10 mm	42 mm	1.654 in
Panasonic Industrial Automation Sales EET-HD2W271JJ	Polar	270 µF	20 %			Through Hole	25 mm	0.984 "	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.666 A	1.19 A	450 V	0.394 in	10 mm	42 mm	1.654 in
Panasonic Industrial Automation Sales EET-HD2S271JJ	Polar	270 µF	20 %			Through Hole	25 mm	0.984 "	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.68 A	1.2 A	420 V	0.394 in	10 mm	42 mm	1.654 in
Panasonic Industrial Automation Sales EET-HD2W181JJ	Polar	180 çF	20 %			Through Hole	25 mm	0.984 "	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	1.218 A	870 mA	450 V	0.394 in	10 mm
Panasonic Industrial Automation Sales EET-HD2W561LJ	Polar	560 µF	20 %			Through Hole	35 mm	1.378 in	3000 Hrs	General Purpose	Radial Can - Snap-In	-25 °C	105 ░C	2.66 A	1.9 A	450 V	0.394 in	10 mm	42 mm	1.654 in
