395-064 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 64POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Number of Rows [custom] | Mounting Type | Color | Card Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Pitch | Pitch | Number of Positions/Bay/Row | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Contact Finish | Number of Positions | Read Out | Contact Material | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Through Hole | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 32 | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Gold | 64 | Dual | Copper Alloy | |||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 64 | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Gold | 64 | Single | Copper Alloy | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 64 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Gold | 64 | Single | Copper Alloy | 1 | 1 | Card Guides | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Through Hole | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 32 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Gold | 64 | Dual | Copper Alloy | Card Guides | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Right Angle Through Hole | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 32 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Gold | 64 | Dual | Copper Alloy | Card Guides | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Through Hole | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 32 | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Gold | 64 | Dual | Copper Alloy | |||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 64 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | Gold | 64 | Single | Copper Alloy | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 64 | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Gold | 64 | Single | Copper Alloy | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Through Hole | Black | Non Specified - Single Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 64 | Female | 4-40 Threaded Insert Top Mount Opening | Solder | Gold | 64 | Single | Copper Alloy | 1 | 1 | Card Guides | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 2 | Board Edge Straddle Mount | Black | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 0.1 " | 2.54 mm | 32 | Female | 4-40 Threaded Insert Top Mount Opening | Solder | Gold | 64 | Dual | Copper Alloy | Card Extender Card Guides |
