Z-10FQ22 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SWITCH SNAP ACTION SPDT 10A 125V
| Part | Operating Position | Operating Position | Current Rating (Amps) | Voltage Rating - AC | Release Force | Mounting Type | Termination Style | Pretravel | Pretravel | Switch Function | Overtravel [custom] | Overtravel [custom] | Differential Travel | Differential Travel | Voltage Rating - DC | Operating Temperature [Min] | Operating Temperature [Max] | Circuit | Actuator Type | Ingress Protection | Operating Force [Min] | Operating Force [Max] | Electrical Life | Mechanical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | 1.313 in | 33.4 mm | 10 A | 125 V | 114 gf | Panel Mount | Screw Terminal | 0.04 in | 1 mm | On-Mom | 0.141 " | 3.6 mm | 0.1 mm | 0.004 in | 30 V | -25 °C | 80 °C | SPDT (DB/DM) | Roller Plunger | IP00 | 455 gf | 740 gf | 100000 Cycles | 500000 Cycles |
