GRTE18S Series
Manufacturer: SICK, Inc.
Beta
⌘K
SENSOR PROXIMITY 550MM PNP
| Part | Sensing Method | Response Time | Ingress Protection | Light Source | Output Configuration | Connection Method | Operating Temperature [Min] | Operating Temperature [Max] | Sensing Distance [Max] | Sensing Distance [Min] | Sensing Distance [Min] | Sensing Distance [Max] | Adjustment Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | PNP | Connector M12 | -25 °C | 55 °C | 21.654 in | 5 mm | 0.197 in | 55 cm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Cable | -25 °C | 55 °C | 4.528 " 115 mm | 0.118 in 3 mm | Adjustable Potentiometer | 10 VDC | 30 VDC | 78.74 " | 2 m | ||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | PNP | Connector M12 | -25 °C | 55 °C | 21.654 in | 5 mm | 0.197 in | 55 cm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||
SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Connector M12 | -25 °C | 55 °C | 4.528 " 115 mm | 0.118 in 3 mm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | PNP | Connector M12 | -25 °C | 55 °C | 39.37 in | 5 mm | 0.197 in | 100 cm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | PNP | Connector M12 | -25 °C | 55 °C | 4.528 " 115 mm | 0.118 in 3 mm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Connector M12 | -25 °C | 55 °C | 4.528 " 115 mm | 0.118 in 3 mm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||||
SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Connector M12 | -25 °C | 55 °C | 39.37 in | 5 mm | 0.197 in | 100 cm | Adjustable Potentiometer | 10 VDC | 30 VDC | ||
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Cable | -25 °C | 55 °C | 39.37 in | 5 mm | 0.197 in | 100 cm | Adjustable Potentiometer | 10 VDC | 30 VDC | 78.74 " | 2 m |
 SICK, Inc. | Proximity | 1 ms | IP67 | RED (650nm) | NPN | Cable | -25 °C | 55 °C | 4.528 " 115 mm | 0.118 in 3 mm | Adjustable Potentiometer | 10 VDC | 30 VDC | 78.74 " | 2 m |
