RJHSE508 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN MOD JACK 8P8C R/A UNSHLD
| Part | Housing Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Connector Type | Number of Ports | LED Color | Mounting Type | Contact Material | Shielding | Number of Positions/Contacts | Features | Termination | Contact Finish | Orientation | Tab Direction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 8 | Yellow - Green | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 2 | Green - Green | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 1 | Does Not Contain LED | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 2 | Green Orange - Green Orange | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 1 | Does Not Contain LED | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 1 | Green Yellow - Yellow | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
 Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 8 | Yellow - Green | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 2 | Green | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 2 | Green Red | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
Amphenol ICC (Commercial Products) | Thermoplastic | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | 8 | Yellow Yellow - Green | Through Hole | Phosphor Bronze | Unshielded | 8p8c (RJ45 Ethernet) | Board Lock | Solder | Gold | 90 ° | Up |
