SM912 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
VALU-BEAM: VISIBLE RED 650 NM CONVERGENT
| Part | Ingress Protection | Sensing Distance | Sensing Distance | Light Source | Sensing Method | Connection Method | Operating Temperature [Min] | Operating Temperature [Max] | Adjustment Type | Output Configuration | Voltage - Supply [Min] | Voltage - Supply [Max] | Cable Length | Cable Length | Response Time | Sensing Distance [Min] | Sensing Distance [Max] | Sensing Distance [Min] | Sensing Distance [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 12 13 13 IEC IP66 2 3 3S 4 4X 6 6P IEC IP66 NEMA 1 | 38 mm | 1.496 in | RED (650nm) | Convergent | Cable | -20 ░C | 70 °C | Adjustable Potentiometer | NPN/PNP - Dark-ON/Light-ON - Selectable | 10 VDC | 30 VDC | 78.74 " | 2 m | 4 ms | ||||
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 6P IEC IP66 NEMA 1 | 760 mm | 29.921 " | Infrared (880nm) | Diffuse | Cable | -20 ░C | 70 °C | Adjustable Potentiometer | NPN/PNP - Dark-ON/Light-ON - Selectable | 10 VDC | 30 VDC | 78.74 " | 2 m | 4 ms | ||||
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X IEC IEC IP66 IP66 NEMA 1 NEMA 12 NEMA 13 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X | Red LED | Retroreflective NonPolarized | Cable | -20 ░C | 70 °C | Adjustable | NPN PNP | 10 VDC | 30 VDC | 78.74 " | 2 m | 8 ms | 5.91 " | 9000 mm | 15 cm | 354.33 in |
