CC15-2403 Series
Manufacturer: TDK Corporation
Beta
⌘K
ISOLATED THROUGH HOLE DC/DC CONVERTER, ULTRA COMPACT, ITE, DIP, 2:1, 15 W, 1 OUTPUT, 3.3 V
| Part | Voltage - Isolation | Package / Case | Power (Watts) | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Type | Number of Outputs | Efficiency | Voltage - Input (Max) [Max] | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Control Features | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 1000 V | 20-DIP Module 17 Leads | 15 W | ITE (Commercial) | 85 °C | -40 C | 3.3 V | 29.6 mm | 6.8 mm | 0.27 " | 1.17 in | 38.4 mm | 1.51 in | Isolated Module | 1 | 89 % | 36 V | 4.5 A | 18 V | Active Low Enable | Through Hole | |
 TDK Corporation | 1000 V | 20-SMD Module 17 Leads | 15 W | ITE (Commercial) | 85 °C | -40 C | 3.3 V | 29.6 mm | 6.8 mm | 0.27 " | 1.17 in | 38.4 mm | 1.51 in | Isolated Module | 1 | 89 % | 36 V | 4.5 A | 18 V | Active Low Enable | Surface Mount | OCP OVP Remote On/Off |
 TDK Corporation | 1000 V | 20-SMD Module 17 Leads | 15 W | ITE (Commercial) | 85 °C | -40 C | 3.3 V | 29.6 mm | 6.8 mm | 0.27 " | 1.17 in | 38.4 mm | 1.51 in | Isolated Module | 1 | 89 % | 36 V | 4.5 A | 18 V | Active Low Enable | Surface Mount | OCP OVP Remote On/Off |
