ESY Series

Manufacturer: KEMET

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 100V 10UF 105C 2K HOUR RADIAL

Part	Mounting Type	Ripple Current @ Low Frequency	Size / Dimension [diameter]	Size / Dimension [diameter]	Polarization	ESR (Equivalent Series Resistance)	Lead Spacing	Lead Spacing	Tolerance	Lifetime @ Temp.	Applications	Voltage - Rated	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Ripple Current @ High Frequency	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Impedance	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]
KEMET ESY106M100AE3AA	Through Hole	119 mA	0.248 "	6.3 mm	Polar	950 mOhm	2.5 mm	0.098 in	20 %	2000 Hrs	General Purpose	100 V	0.492 in	12.5 mm	170 mA	10 µF	-40 C	105 ░C	950 mOhms	Can Radial
KEMET ESY227M050AH2AA	Through Hole	959 mA	0.394 in	10 mm	Polar	42 mOhm	5 mm	0.197 "	20 %	4000 Hrs	General Purpose	50 VDC	17 mm		1.37 A	220 µF	-40 C	105 ░C	42 mOhms	Can Radial	0.669 "
KEMET ESY226M050AE2KA	Through Hole	210 mA	0.248 "	6.3 mm	Polar	260 mOhm	2.5 mm	0.098 in	20 %	1000 Hrs	General Purpose	50 VDC	8.5 mm		300 mA	22 µF	-40 C	105 ░C	260 mOhms	Can Radial		0.335 "
KEMET ESY107M100AH5AA	Through Hole	616 mA	0.394 in	10 mm	Polar	120 mOhm	5 mm	0.197 "	20 %	4000 Hrs	General Purpose	100 V	27 mm		880 mA	100 µF	-40 C	105 ░C	120 mOhms	Can Radial		1.063 in
KEMET ESY397M100AN5AA	Through Hole	1.134 A	0.709 in	18 mm	Polar	49 mOhm	7.5 mm	0.295 in	20 %	5000 Hrs	General Purpose	100 V	27 mm		1.62 A	390 µF	-40 C	105 ░C	49 mOhms	Can Radial		1.063 in
KEMET ESY227M035AH1AA	Through Hole	721 mA	0.394 in	10 mm	Polar	53 mOhm	5 mm	0.197 "	20 %	4000 Hrs	General Purpose	35 V	13.5 mm		1.03 A	220 µF	-40 C	105 ░C	53 mOhms	Can Radial		0.531 in
KEMET ESY158M6R3AH4AA	Through Hole	1.456 A	0.394 in	10 mm	Polar	26 mOhm	5 mm	0.197 "	20 %	4000 Hrs	General Purpose	6.3 VDC			1.82 A	1.5 mF	-40 C	105 ░C	26 mOhms	Can Radial			0.866 in	22 mm
KEMET ESY157M035AG3AA	Through Hole	532 mA	0.315 in	8 mm	Polar	72 mOhm	3.5 mm	0.138 in	20 %	3000 Hrs	General Purpose	35 V	0.492 in	12.5 mm		150 µF	-40 C	105 ░C	72 mOhms	Can Radial
