634M SERIES RIGHT ANGLE D-SUB
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Material Flammability Rating | Backset Spacing | Backset Spacing | Flange Feature | Current Rating (Amps) | Contact Finish | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Termination | Connector Type | Mounting Type | Number of Rows [custom] | Features | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Contact Type | Number of Positions | Shell Material, Finish | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | 4-40 | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Board Lock Mounting Brackets Shielded | 2 | DA A | Signal | 26 | |||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | 4-40 | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Mounting Brackets Shielded | 2 | DA A | Signal | 26 | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | 4-40 | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Board Lock Mounting Brackets Shielded | 2 | DA A | Signal | 26 | Nickel Plated Steel | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell | 5 A | Gold | D-Sub High Density | 0.76 Ám | 30 Áin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Shielded | 2 | DA A | Signal | 26 | 4-40 | ||
 EDAC Inc. | White | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell | 5 A | Gold | D-Sub High Density | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Mounting Brackets Shielded | 2 | DA A | Signal | 26 | Nickel Plated Steel | 4-40 | Flash | ||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Board Lock Mounting Brackets Shielded | 2 | DA A | Signal | 26 | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | White | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Shielded | 2 | DA A | Signal | 26 | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | White | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell | 5 A | Gold | D-Sub High Density | 0.38 µm | 15 µin | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Shielded | 2 | DA A | Signal | 26 | 4-40 | ||
 EDAC Inc. | White | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | 4-40 | 5 A | Gold | D-Sub High Density | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Mounting Brackets Shielded | 2 | DA A | Signal | 26 | Flash | ||||
 EDAC Inc. | Black | -55 C | 125 °C | Copper Alloy | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 8.89 mm | 0.35 in | Housing/Shell (Unthreaded) | 5 A | Gold | D-Sub High Density | Solder | Receptacle Female Sockets | Board Edge Right Angle Through Hole | 3 | Shielded | 2 | DA A | Signal | 26 | Flash |
