Surface Mount Fuses
Surface Mount Fuses
| Part | Mounting Type | Current Rating (Amps) | Package / Case | Voltage Rating - DC | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Approval Agency | Voltage Rating - AC | Operating Temperature [Min] | Operating Temperature [Max] | Fuse Type | DC Cold Resistance | Breaking Capacity @ Rated Voltage | Melting I²t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Surface Mount | 35 A | 2-SMD Square End Block | 125 VDC | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | cURus TUV | 250 V | -55 C | 125 °C | Board Mount (Cartridge Style Excluded) | |||
 Bel Fuse Inc. | Surface Mount | 20 A | 2-SMD Square End Block | 125 VDC | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | AEC-Q200 cURus | 250 V | -55 C | 125 °C | Board Mount (Cartridge Style Excluded) | 0.0028 Ohms | 1.5 kA 100 A | 420 |
 Bel Fuse Inc. | Surface Mount | 35 A | 2-SMD Square End Block | 125 VDC | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | cURus TUV | 250 V | -55 C | 125 °C | Board Mount (Cartridge Style Excluded) | |||
Bel Fuse Inc. | Surface Mount | 10 A | 2-SMD Square End Block | 125 VDC | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | cURus TUV | 250 V | -55 C | 125 °C | Board Mount (Cartridge Style Excluded) | 90 | ||
Bel Fuse Inc. | Surface Mount | 30 A | 2-SMD Square End Block | 125 VDC | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | cURus TUV | 250 V | -55 C | 125 °C | Board Mount (Cartridge Style Excluded) | 2000 |
