SSF67 Series
Manufacturer: Sensata-Crydom
Beta
⌘K
DL LVL FLOATSW 277MM TOTAL L
| Part | Operating Temperature | Type | Material - Housing & Prism | Minimum Liquid Specific Gravity [Min] | Output Configuration [custom] | Mounting Type | Output Type | Voltage Rating | Voltage Rating | Switch Actuation Level | Switch Actuation Level | Current | Output Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | SPST-NC SPST-NO | M16x2 Thread Panel Mount | Switch (2) (Single Float) | 250 VAC | 120 VDC | 0.984 " 9.842 " | 25 mm 250 mm | 600 mA | |
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | SPST-NC SPST-NO | M16x2 Thread Panel Mount | Switch (2) (Single Float) | 250 VAC | 120 VDC | 0.984 in 8.858 in | 600 mA | ||
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 120 VDC 240 VAC | 1.969 in 7.874 in | SPST-NC | ||||
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | SPST-NC SPST-NO | M16x2 Thread Panel Mount | Switch (2) (Single Float) | 250 VAC | 120 VDC | 0.984 " 7.874 " | 25 mm 200 mm | 600 mA | |
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 250 VAC | 120 VDC | 1.969 in 5.906 " 50 mm 150 mm | 600 mA | SPST-NO | ||
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 250 VAC | 120 VDC | 1.969 in 5.906 " 50 mm 150 mm | 600 mA | SPST-NC | ||
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 250 VAC | 120 VDC | 50 mm 100 mm | 1.969 in 3.937 in | 600 mA | SPST-NO | |
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 250 VAC | 120 VDC | 50 mm 100 mm | 1.969 in 3.937 in | 600 mA | SPST-NC | |
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | M16x2 Thread Panel Mount | Switch (2) (Dual Float) | 250 VAC | 120 VDC | 1.969 " 50 mm 300 mm | 600 mA | SPST-NC | ||
 Sensata-Crydom | 135 °C | Liquid | 316 Stainless Steel | 0.8 | SPST-NC SPST-NO | M16x2 Thread Panel Mount | Switch (2) (Single Float) | 250 VAC | 120 VDC | 0.984 in 11.811 " | 600 mA |
