BPSY Series

Catalog

POWER INDUCTORS - SMD CHILISIN POWER - INDUCTOR (IND) FERRITE SMD SHIELDED TYPE

Part	Current Rating (Amps)	DC Resistance (DCR) [Max]	Package / Case	Inductance	Tolerance	Q @ Freq	Material - Core	Operating Temperature [Max]	Operating Temperature [Min]	Shielding	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Current - Saturation (Isat)	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max)	Frequency - Self Resonant	Inductance Frequency - Test	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Pulse Electronics BPSY00191576330M00	2.8 A	75 mOhm	Nonstandard	33 µH	20 %	40 100 kHz	Ferrite	125 °C	-40 C	Shielded	0.6 in	0.73 in	15.24 mm	18.54 mm	3.3 A	Surface Mount	0.3 in	7.62 mm	11 MHz	100 kHz
Pulse Electronics BPSY00130951330M00	1.1 A	334 mOhm	Nonstandard	33 µH	20 %	20 100 kHz	Ferrite	125 °C	-40 C	Shielded	9.4 mm	12.95 mm	0.37 in	0.51 "	1.4 A	Surface Mount			12 MHz	100 kHz	5.08 mm	0.2 in
