BARRIER TERMINAL BLOCKS 8DBL-06-007 8DBL-06-007
| Part | Number of Wire Entries | Color | Pitch [x] | Pitch [x] | Number of Circuits | Terminal Block Type | Voltage Rating | Top Termination | Bottom Termination | Current Rating (Amps) | Wire Gauge [Min] | Wire Gauge [Max] | Number of Rows | Barrier Type | Terminal Screw Finish | Terminal Screw Material | Material Flammability Rating | Mounting Type | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Features | Number of Circuits [custom] | Pitch | Pitch | Bottom Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 6 | Black | 0.438 in | 11.12 mm | 6 | Barrier Block | 600 V | Screws | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | ||||||||||||
 TE Connectivity AMP Connectors | 2 | Black | 0.438 in | 11.12 mm | 2 | Barrier Block | 600 V | Screws with Captive Plate | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | Zinc | Steel | UL94 V-0 | Chassis Panel Through Hole | Thermoplastic | 120 °C | -40 C | Flange | ||||
 TE Connectivity AMP Connectors | 9 | Black | Barrier Block | 600 V | Screws | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | 9 | 0.437 " | 11.1 mm | ||||||||||||
 TE Connectivity AMP Connectors | 2 | Black | 0.438 in | 11.12 mm | 2 | Barrier Block | 600 V | Screws | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | Zinc | Steel | UL94 V-0 | Through Hole | Thermoplastic | 120 °C | -40 C | |||||
 TE Connectivity AMP Connectors | 6 | Black | 0.438 in | 11.12 mm | 6 | Barrier Block | 600 V | Screws | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | ||||||||||||
 TE Connectivity AMP Connectors | 2 | Black | 0.438 in | 11.12 mm | 2 | Barrier Block | 600 V | Screws | Quick Connect | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | Zinc | Steel | UL94 V-0 | Chassis Panel | Thermoplastic | 120 °C | -40 C | 0.187 in | ||||
 TE Connectivity AMP Connectors | 14 | Black | 0.438 in | 11.12 mm | 14 | Barrier Block | 600 V | Screws with Captive Plate | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | ||||||||||||
 TE Connectivity AMP Connectors | 3 | Black | 0.438 in | 11.12 mm | 3 | Barrier Block | 600 V | Screws with Captive Plate | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | ||||||||||||
 TE Connectivity AMP Connectors | 6 | Black | 0.438 in | 11.12 mm | 6 | Barrier Block | 600 V | Screws with Captive Plate | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | ||||||||||||
TE Connectivity AMP Connectors | 3 | Black | 0.438 in | 11.12 mm | 3 | Barrier Block | 600 V | Screws with Captive Plate | PC Pin | 30 A | 10 AWG | 18 AWG | 1 | 3 Wall (Tri) | Zinc | Steel | UL94 V-0 | Chassis Panel Through Hole | Thermoplastic | 120 °C | -40 C | Flange |
