T18SP6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
EZ-BEAM T18 SERIES: RETRORAN
| Part | Ingress Protection | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Configuration | Light Source | Response Time | Sensing Method | Adjustment Type | Operating Temperature [Max] | Operating Temperature [Min] | Cable Length | Cable Length | Sensing Distance | Sensing Distance | Connection Method |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON - Selectable | Infrared | 3 ms | Retroreflective NonPolarized | Adjustable Potentiometer | 70 °C | -40 C | 78.74 " | 2 m | 2 m | 78.74 in | Cable |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (880nm) | 3 ms | Background Suppression | 70 °C | -40 C | 10 cm | 3.937 in | Connector | |||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON - Selectable | Infrared | 3 ms | Background Suppression | 70 °C | -40 C | 10 cm | 3.937 in | Connector | |||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (880nm) | 3 ms | Background Suppression | 70 °C | -40 C | 5 cm | 1.969 in | Connector | |||
 BANNER ENGINEERING | IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (880nm) | 3 ms | Diffuse | Adjustable Potentiometer | 70 °C | -40 C | 50 cm | 19.685 in | Connector | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (880nm) | 3 ms | Diffuse | Adjustable Potentiometer | 70 °C | -40 C | 78.74 " | 2 m | 50 cm | 19.685 in | Cable |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON - Selectable | Red LED | 3 ms | Polarized Retroreflective | 70 °C | -40 C | 2 m | 78.74 in | Connector | |||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (950nm) | 3 ms | Retroreflective NonPolarized | Adjustable Potentiometer | 70 °C | -40 C | 2 m | 78.74 in | Connector | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (950nm) | 3 ms | Through-Beam | 70 °C | -40 C | 2000 cm | 787.402 in | Connector | |||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | 10 VDC | 30 VDC | PNP - Dark-ON/Light-ON | Infrared (950nm) | 3 ms | Through-Beam | 70 °C | -40 C | 78.74 " | 2 m | 2000 cm | 787.402 in | Cable |
