857-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 25POS 0.156
| Part | Material - Insulation | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Card Type | Termination | Number of Rows | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Gender | Number of Positions/Bay/Row | Read Out | Number of Positions | Contact Material | Mounting Type | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | 1 | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Single | 25 | Copper Alloy | Right Angle Through Hole | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | Non Specified - Single Edge | Wire Wrap | 1 | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Single | 25 | Copper Alloy | Through Hole | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | 1 | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Single | 25 | Copper Alloy | Right Angle Through Hole | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Dual | 50 | Copper Alloy | Right Angle Through Hole | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Black | 125 °C | -40 C | Gold | Semi Bellows | Female | 25 | Dual | 50 | Copper Alloy | Right Angle Through Hole | 2 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | 1 | Black | 125 °C | -40 C | Gold | Semi Bellows | Female | 25 | Single | 25 | Copper Alloy | Right Angle Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Dual | 50 | Copper Alloy | Through Hole | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Non Specified - Single Edge | Solder | 1 | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Single | 25 | Copper Alloy | Through Hole | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder | Black | 125 °C | -40 C | Tin | Semi Bellows | Female | 25 | Dual | 50 | Copper Alloy | Right Angle Through Hole | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Solder Eyelet(s) | Black | 125 °C | -40 C | Gold | Semi Bellows | Female | 25 | Dual | 50 | Copper Alloy | Through Hole | 2 | 0.25 Ám | 10 Áin |
