325-046 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 46POS 0.100
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Mounting Type | Card Thickness | Card Thickness | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Number of Positions | Contact Type | Contact Material | Flange Feature | Color | Contact Finish | Card Type | Pitch | Pitch | Gender | Contact Finish Thickness | Contact Finish Thickness | Read Out | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Solder | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 23 | Through Hole | 3.18 mm | 0.125 in | Solder | -65 ░C | 125 °C | 46 | Cantilever | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Green | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Dual | 2 | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single | |||||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Solder | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | Flush Mount Top Opening Unthreaded | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single | 0.16 " | 4.06 mm | ||
EDAC Inc. | Diallyl Phthalate (DAP) | 23 | Through Hole | 3.18 mm | 0.125 in | Solder | -65 ░C | 125 °C | 46 | Cantilever | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Green | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Dual | 2 | 2 | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | 23 | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | -65 ░C | 125 °C | 46 | Cantilever | Copper Alloy | Flush Mount Top Opening Unthreaded | Green | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Dual | 2 | 2 | 0.16 " | 4.06 mm | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 23 | Through Hole | 3.18 mm | 0.125 in | Solder | -65 ░C | 125 °C | 46 | Cantilever | Copper Alloy | Green | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Dual | 2 | 2 | |||||
EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 46 | Through Hole | 3.18 mm | 0.125 in | Wire Wrap | -65 ░C | 125 °C | 1 | 46 | Cantilever | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Green | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | Female | 0.25 Ám | 10 Áin | Single |
