PTC23 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER VERT 23POS 2.54MM

Part	Pitch - Mating	Pitch - Mating	Fastening Type	Number of Positions	Shrouding	Overall Contact Length	Overall Contact Length	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Termination	Mounting Type	Connector Type	Contact Length - Post	Contact Length - Post	Current Rating (Amps)	Contact Shape	Insulation Material	Number of Positions Loaded	Number of Rows	Insulation Color	Contact Material	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Style	Insulation Height	Insulation Height	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Insulation Height [z]	Insulation Height [z]	Overall Contact Length [x]	Overall Contact Length [x]
Sullins Connector Solutions PTC23SFEN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded	23.83 mm	0.938 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.52 in	13.21 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	8.08 mm	0.318 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm
Sullins Connector Solutions PTC23SFBN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded	16.21 mm	0.638 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.22 in	5.58 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	8.08 mm	0.318 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm
Sullins Connector Solutions PTC23DBAN	0.1 "	2.54 mm	Push-Pull	46	Unshrouded			2.54 µm	100 µin	Solder	Right Angle Through Hole	Header	0.12 in	3.05 mm	3 A	Square	Polyester Thermoplastic	All		Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable			0.1 in	2.54 mm	2	6.1 mm	0.24 in
Sullins Connector Solutions PTC23SAHN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded	29.21 mm	1.15 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.82 in	20.83 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm
Sullins Connector Solutions PTC23DAHN	0.1 "	2.54 mm	Push-Pull	46	Unshrouded	29.21 mm	1.15 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.82 in	20.83 mm	3 A	Square	Polyester Thermoplastic	All		Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm	0.1 in	2.54 mm	2
Sullins Connector Solutions PTC23SAEN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded	21.59 mm	0.85 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.52 in	13.21 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm
Sullins Connector Solutions PTC23DAGN	0.1 "	2.54 mm	Push-Pull	46	Unshrouded	26.67 mm	1.05 in	2.54 µm	100 µin	Solder	Through Hole	Header	0.72 "	18.29 mm	3 A	Square	Polyester Thermoplastic	All		Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm	0.1 in	2.54 mm	2
Sullins Connector Solutions PTC23DADN	0.1 "	2.54 mm	Push-Pull	46	Unshrouded			2.54 µm	100 µin	Solder	Through Hole	Header	0.42 in	10.67 mm	3 A	Square	Polyester Thermoplastic	All		Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm	0.1 in	2.54 mm	2			19.05 mm	0.75 in
Sullins Connector Solutions PTC23SAAN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded			2.54 µm	100 µin	Solder	Through Hole	Header	0.12 in	3.05 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.1 in	2.54 mm						11.43 mm	0.45 in
Sullins Connector Solutions PTC23SBDN	0.1 "	2.54 mm	Push-Pull	23	Unshrouded			2.54 µm	100 µin	Solder	Right Angle Through Hole	Header	0.42 in	10.67 mm	3 A	Square	Polyester Thermoplastic	All	1	Black	Copper Alloy	Tin	5.84 mm	0.23 in	Male Pin	100 çin	2.54 çm	UL94 V-0	Board to Board Cable	0.14 in	3.56 mm
