MAX22665 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
6 CHANNEL REINFORCED ISOLATOR
| Part | Grade | Mounting Type | Channel Type | Propagation Delay tpLH / tpHL (Max) | Number of Channels [custom] | Technology | Qualification | Data Rate | Voltage - Supply [Max] | Voltage - Supply [Min] | Pulse Width Distortion (Max) [Max] | Supplier Device Package | Isolated Power | Package / Case [x] | Package / Case | Package / Case [y] | Type | Rise / Fall Time (Typ) [custom] | Rise / Fall Time (Typ) [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Inputs - Side 1/Side 2 [custom] | Inputs - Side 1/Side 2 [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | |||||||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Automotive | Surface Mount | Unidirectional | 9.5 ns 9.9 ns | 6 | Capacitive Coupling | AEC-Q100 | 200 Mbps | 5.5 V | 1.71 V | 2 ns | 16-SOIC | 0.295 in | 16-SOIC | 7.5 mm | CAN RS232 RS422 RS485 SPI | 0.8 ns | 1 ns | 125 °C | -40 °C | 1 | 5 |
