MINI-CON-X CABLE-TO-CABLE, 7-PIN #20, MALE, CRIMP, BULK
| Part | Mounting Type | Termination | Backshell Material, Plating | Fastening Type | Ingress Protection | Orientation | Primary Material | Applications | Current Rating (Amps) | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Shielding | Connector Type | Color | Contact Finish - Mating | Contact Material | Features | Voltage Rating | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 7 | 115 °C | -40 C | 4.57 mm | 0.18 " | 0.2 " | 5.08 mm | Unshielded | Receptacle Male Pins | Black | Gold | Brass | Backshell | 600 V | |
SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 4 | 115 °C | -40 C | 5.33 mm | 0.21 in | 0.23 in | 5.84 mm | Unshielded | Plug Male Pins | Black | Gold | Brass | Backshell | 600 V | |
 SWITCHCRAFT/CONXALL | Panel Mount | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 6 | 115 °C | -40 C | Unshielded | Receptacle Male Pins | Black | Gold | Brass | 600 V | Bulkhead - Front Side Nut | |||||
 SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 115 °C | -40 C | 5.33 mm | 0.21 in | 0.23 in | 5.84 mm | Unshielded | Plug Male Pins | Black | Gold | Brass | Backshell | 600 V | ||
 SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 5 | 115 °C | -40 C | 5.59 mm | 0.22 in | 0.25 in | 6.35 mm | Unshielded | Plug Female Sockets | Black | Gold | Brass | Backshell | 600 V | |
 SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 5 | 115 °C | -40 C | Unshielded | Plug Female Sockets | Black | Gold | Brass | Backshell | 600 V | |||||
 SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 4 | 115 °C | -40 C | 5.33 mm | 0.21 in | 0.23 in | 5.84 mm | Unshielded | Receptacle Female Sockets | Black | Gold | Brass | Backshell | 600 V | |
SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 115 °C | -40 C | 3.3 mm | 0.13 " | 0.15 in | 3.81 mm | Unshielded | Plug Male Pins | Black | Gold | Brass | Backshell | 600 V | ||
SWITCHCRAFT/CONXALL | Free Hanging (In-Line) | Crimp | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 5 | 115 °C | -40 C | 3.3 mm | 0.13 " | 0.15 in | 3.81 mm | Unshielded | Plug Male Pins | Black | Gold | Brass | Backshell | 600 V | |
 SWITCHCRAFT/CONXALL | Panel Mount Through Hole | Solder | Nylon Polyamide (PA) | Bayonet Lock | Weathertight | Keyed | Plastic | Automotive Communication Systems Instrumentation | Varies by Wire Gauge | 5 | 115 °C | -40 C | Unshielded | Receptacle Male Pins | Black | Gold | Brass | 600 V | Bulkhead - Front Side Nut |
