RP506 Series

Catalog

SWITCHING VOLTAGE REGULATORS 2A PWM/VFM STEP-DOWN DC/DC CONVERTER WITH SYNCHRONOUS RECTIFIER FOR AUTOMOTIVE APPLICATIONS

Part	Qualification	Current - Output	Number of Outputs	Topology	Supplier Device Package	Voltage - Output (Min/Fixed)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Mounting Type	Grade	Package / Case	Voltage - Input (Min) [Min]	Frequency - Switching	Output Configuration	Function
Nisshinbo Micro Devices Inc. RP506L331H-TR-K	AEC-Q100	2 A	1	Buck	DFN3030-12	3.3 V	125 °C	-40 °C	5.5 V	Surface Mount	Automotive	12-WFDFN Exposed Pad	2.5 V	2.3 MHz	Positive	Step-Down
Nisshinbo Micro Devices Inc. RP506K111E-TR		2 A	1	Buck	DFN(PL)2527-10	1.1 V	85 C	-40 ¯C	5.5 V	Surface Mount		10-UFDFN Exposed Pad	2.5 V	1.2 MHz	Positive	Step-Down
Nisshinbo Micro Devices Inc. RP506K121E-TR		2 A	1	Buck	DFN(PL)2527-10	1.2 V	85 C	-40 ¯C	5.5 V	Surface Mount		10-UFDFN Exposed Pad	2.5 V	1.2 MHz	Positive	Step-Down
Nisshinbo Micro Devices Inc. RP506L101G-TR-K	AEC-Q100	2 A	1	Buck	DFN3030-12	1 V	125 °C	-40 °C	5.5 V	Surface Mount	Automotive	12-WFDFN Exposed Pad	2.5 V	2.3 MHz	Positive	Step-Down
Nisshinbo Micro Devices Inc. RP506K111D-TR		2 A	1	Buck	DFN(PL)2527-10	1.1 V	85 C	-40 ¯C	5.5 V	Surface Mount		10-UFDFN Exposed Pad	2.5 V	1.2 MHz	Positive	Step-Down
