B Series
Manufacturer: ODU
Beta
⌘K
ODU MINI-SNAP PLUG, STY 3, SZ 2,
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Orientation | Number of Positions | Applications | Shell Finish | Backshell Material, Plating | Insert Material | Shielding | Primary Material | Shell Material | Connector Type | Contact Finish - Mating | Cable Opening [Min] | Cable Opening [Max] | Fastening Type | Contact Material | Mounting Type | Color | Shell Size - Insert [custom] | Ingress Protection | Voltage Rating | Features | Cable Opening [Max] | Cable Opening [Min] | Shell Size - Insert | Mounting Feature | Termination | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
120 °C | -40 C | 12 Amps | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.335 in 8.5 mm | 0.354 in 9 mm | Push-Pull | Brass | Free Hanging (In-Line) | Silver | 2 | IP68 - Dust Tight Waterproof | 650 V | Backshell | |||||||
120 °C | -40 C | 7.5 A | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Receptacle Female Sockets | Gold | 0.177 in | 0.197 in | Push-Pull | Brass | Free Hanging (In-Line) | Silver | 0 | IP68 - Dust Tight Waterproof | 300 VDC | Backshell Strain Relief | 5 mm | 4.5 mm | |||||
120 °C | -40 C | 7.5 A | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Receptacle Female Sockets | Gold | Push-Pull | Brass | Panel Mount | Silver | IP68 - Dust Tight Waterproof | 500 V | Ground | 1 | Bulkhead - Front Side Nut | |||||||||
120 °C | -40 C | 6 A | 5 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Receptacle Female Sockets | Gold | Push-Pull | Brass | Panel Mount Through Hole | Silver | 0 | IP68 - Dust Tight Waterproof | 366 V | Ground | Bulkhead - Front Side Nut | Solder | A | ||||||||
120 °C | -40 C | 7.5 A | 14 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.256 in | 0.276 " | Push-Pull | Brass | Free Hanging (In-Line) | Silver | 2 | IP68 - Dust Tight Waterproof | 366 V | Backshell | 7 mm | 6.5 mm | F | |||||
120 °C | -40 C | 7.5 A | 0 | 22 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.138 " | 0.157 in | Push-Pull | Brass | Free Hanging (In-Line) | Silver | IP68 - Dust Tight Waterproof | 333 V | Backshell | 4 mm | 3.5 mm | 3 TPI | |||||
120 °C | -40 C | 18 A | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Receptacle Female Sockets | Gold | Push-Pull | Brass | Panel Mount | Silver | IP68 - Dust Tight Waterproof | 600 V | Ground | 3 TPI | Bulkhead - Rear Side Nut | |||||||||
120 °C | -40 C | 7.5 A | 0 | 2 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.157 in | 0.177 " | Push-Pull | Brass | Free Hanging (In-Line) | Silver | 0 | IP68 - Dust Tight Waterproof | 500 V | Backshell Strain Relief | 4.5 mm | 4 mm | |||||
120 °C | -40 C | 18 A | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.118 in | 0.138 in | Push-Pull | Brass | Free Hanging (In-Line) | Silver | IP68 - Dust Tight Waterproof | 600 V | Backshell Strain Relief | 3.5 mm | 3 mm | 3 TPI | |||||
120 °C | -40 C | 15 A | 0 | 4 | Industrial Medical Military Testing Equipment & Measurement | Chrome over Nickel | Brass Chrome over Nickel | Polyetheretherketone (PEEK) | Unshielded | Metal | Brass | Plug Male Pins | Gold | 0.118 in | 0.138 in | Push-Pull | Brass | Free Hanging (In-Line) | Silver | 2 | IP68 - Dust Tight Waterproof | 600 V | Backshell Strain Relief | 3.5 mm | 3 mm |
