ETQ-P3 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
FIXED IND 2.2UH 5.8A 24.8MOHM SM
| Part | Current Rating (Amps) | Ratings | Package / Case | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Tolerance | Material - Core | Height - Seated (Max) | Height - Seated (Max) [Max] | Shielding | Mounting Type | Inductance Frequency - Test | Type | Inductance | Current - Saturation (Isat) | DC Resistance (DCR) [Max] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | DC Resistance (DCR) | Package / Case | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | 5.8 A | AEC-Q200 | 2-SMD J-Lead | 5 mm | 0.217 " | 0.197 " | 5.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 2.2 µH | 10.9 A | 24.8 mOhm | ||||||||
 Panasonic Industrial Automation Sales | 5.7 A | 2-SMD J-Lead | 6.6 mm | 0.276 " | 0.26 " | 7 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | 4.7 ÁH | 40.3 mOhm | |||||||||||
 Panasonic Industrial Automation Sales | 2.1 A | AEC-Q200 | 2-SMD J-Lead | 6 mm | 6.4 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 33 µH | 3 A | 226.6 mOhm | 0.236 " | 0.252 " | 155 °C | -55 °C | ||||||
Panasonic Industrial Automation Sales | 6.3 A | AEC-Q200 | 2-SMD J-Lead | 5 mm | 0.217 " | 0.197 " | 5.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 2.2 µH | 10.1 A | 155 °C | -55 °C | |||||||
Panasonic Industrial Automation Sales | 21 A | 2-SMD J-Lead | 6.6 mm | 0.276 " | 0.26 " | 7 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | 330 nH | 3.9 mOhm | |||||||||||
Panasonic Industrial Automation Sales | 8.1 A | AEC-Q200 | 2-SMD J-Lead | 5 mm | 0.217 " | 0.197 " | 5.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 1.5 µH | 13.2 mOhm | 155 °C | -55 °C | |||||||
Panasonic Industrial Automation Sales | 5.6 A | AEC-Q200 | 2-SMD J-Lead | 6 mm | 0.256 " | 0.236 in | 6.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | 1.5 µH | 11 mOhm | ||||||||||
 Panasonic Industrial Automation Sales | 2.5 A | AEC-Q200 | 2-SMD J-Lead | 6 mm | 0.256 " | 0.236 in | 6.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 22 µH | 4 A | 158.4 mOhm | ||||||||
Panasonic Industrial Automation Sales | AEC-Q200 | 2-SMD J-Lead | 5 mm | 0.217 " | 0.197 " | 5.5 mm | 20 % | Metal Composite | 3 mm | 0.118 in | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 1 µH | 14.1 A | 155 °C | -55 °C | 10.56 mOhm | |||||||
 Panasonic Industrial Automation Sales | 16 A | Nonstandard | 12.9 mm | 0.512 in | 0.508 in | 13 mm | 20 % | Ferrite | Shielded | Surface Mount | 100 kHz | Drum Core Wirewound | 800 nH | 2.33 mOhm | 4 Lead | 0.154 in | 3.9 mm |
