Triple 3-input AND gate
Description
AI
The 74LVC11-Q100 provides three 3-input AND functions.
Beta
⌘K
Triple 3-input AND gate
Triple 3-input AND gate
| Part | Logic Type | Package / Case | Supplier Device Package | Input Logic Level - High [Max] [x] | Input Logic Level - High [Min] [x] | Current - Quiescent (Max) [Max] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Inputs | Current - Output High, Low [custom] | Current - Output High, Low [custom] | Input Logic Level - Low [Min] | Input Logic Level - Low [Max] | Qualification | Grade | Voltage - Supply [Min] | Voltage - Supply [Max] | Max Propagation Delay @ V, Max CL | Number of Circuits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nexperia USA Inc. | AND Gate | 14-VFQFN Exposed Pad | 14-DHVQFN (2.5x3) | 2 V | 1.08 V | 40 µA | Surface Mount | 125 °C | -40 C | 3 | 24 mA | 24 mA | 0.12 V | 0.8 V | AEC-Q100 | Automotive | 1.65 V | 3.6 V | 7.2 ns | 3 |
