AMK105B Series

Catalog

CAP CERAMIC 2.2UF 4V X5R 20% PAD SMD 0402 85°C LOW ESR AUTOMOTIVE AEC-Q200 T/R

Part	Capacitance	Ratings	Mounting Type	Applications	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Tolerance	Package / Case	Temperature Coefficient	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Thickness (Max)	Thickness (Max) [Max]
Taiyo Yuden AMK105BJ225MVHF	2.2 µF	AEC-Q200	MLCC Surface Mount	Automotive	-55 C	85 °C	4 V	20 %	0402 (1005 Metric)	X5R	0.02 in	0.5 mm	0.039 "	1 mm	0.55 mm	0.022 in
Taiyo Yuden AMK105BJ475MV-F	4.7 µF		MLCC Surface Mount	SMPS Filtering	-55 C	85 °C	4 V	20 %	0402 (1005 Metric)	X5R	0.02 in	0.5 mm	0.039 "	1 mm	0.55 mm	0.022 in
Taiyo Yuden AMK105BJ225MP-F	2.2 µF		MLCC Surface Mount	SMPS Filtering	-55 C	85 °C	4 V	20 %	0402 (1005 Metric)	X5R	0.02 in	0.5 mm	0.039 "	1 mm	0.33 mm	0.013 "
Taiyo Yuden AMK105B7474KVHF	0.47 µF	AEC-Q200	MLCC Surface Mount	Automotive	-55 C	125 °C	4 V	10 %	0402 (1005 Metric)	X7R	0.02 in	0.5 mm	0.039 "	1 mm	0.55 mm	0.022 in
