895-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 43POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Number of Rows | Contact Finish | Color | Contact Finish Thickness | Contact Finish Thickness | Card Type | Read Out | Pitch | Pitch | Number of Positions/Bay/Row | Mounting Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Cantilever | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Right Angle Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | 0.156 " | 3.96 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Cantilever | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | 0.156 " | 3.96 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Cantilever | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | 0.128 " | 3.25 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Cantilever | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Right Angle Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | 0.156 " | 3.96 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Cantilever | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 43 | 125 °C | -40 C | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Copper Alloy | 1 | Gold | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Single | 0.1 " | 2.54 mm | 43 | Through Hole | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Cantilever |
